DAUNF1305 Straight Connector SAE Female O Ring – SAE Male O Ring

  • DCompanyDME
  • AProduct RangeAdaptor
  • UNThread TypesSAE UNF
  • FConnection TypeFemale
  • 1Adaptor StructureStraight
  • 30Thread TypesSAE UNF
  • 5Connection TypeMale O Ring
  • DME&JDE Code: DAUNF1305
  • Product Type: hydraulic adaptor
  • Standard: JIC and SAE-ORB
  • Structure: Straight
  • Connection Type: Female × Male
  • Thread Types: UNF × UNF
  • Sealing Method: O Rings
Technical Data of DAUNF1305
  • -03
  • -04
  • -05
  • -06
  • -08
  • -10
  • -12
  • -14
  • -16
  • -20
  • -24
  • -32

* Filter the F1 Thread through selecting the -XX options

A drawing of DAUNF1305 hydraulic adaptor.
- Part Number F1 (Thread) F2 (Thread) C D L S Hex
- - UNF UNF mm mm mm - -
-01 DAUNF1305-0304 3/8"-24 7/16"-20 9.14 4.37 27.90 17 mm Metric
-01 DAUNF1305-0308 3/8"-24 3/4"-16 11.13 7.92 20.32 22 mm Metric
-01 DAUNF1305-0304IN 3/8"-24 7/16"-20 9.14 4.37 27.90 5/8" Imperial
-01 DAUNF1305-0308IN 3/8"-24 3/4"-16 11.13 7.92 20.32 7/8" Imperial
-04 DAUNF1305-0402 7/16"-20 5/16"-24 7.54 1.60 28.70 17 mm Metric
-04 DAUNF1305-0403 7/16"-20 3/8"-24 7.54 3.18 28.70 17 mm Metric
-04 DAUNF1305-0404 7/16"-20 7/16"-20 9.14 4.37 28.10 17 mm Metric
-04 DAUNF1305-0405 7/16"-20 1/2"-20 9.14 5.94 27.40 17 mm Metric
-04 DAUNF1305-0406 7/16"-20 9/16"-18 9.93 7.54 28.40 17 mm Metric
-04 DAUNF1305-0408 7/16"-20 3/4"-16 11.13 9.80 27.94 22 mm Metric
-04 DAUNF1305-0410 7/16"-20 7/8"-14 12.70 12.29 23.90 27 mm Metric
-04 DAUNF1305-0412 7/16"-20 1-1/16"-12 15.09 15.47 27.70 32 mm Metric
-04 DAUNF1305-0416 7/16"-20 1-5/16"-12 15.09 9.25 25.40 41 mm Metric
-04 DAUNF1305-0402IN 7/16"-20 5/16"-24 7.54 1.60 28.70 11/16" Imperial
-04 DAUNF1305-0403IN 7/16"-20 3/8"-24 7.54 3.18 28.70 11/16" Imperial
-04 DAUNF1305-0404IN 7/16"-20 7/16"-20 9.14 4.37 28.10 11/16" Imperial
-04 DAUNF1305-0405IN 7/16"-20 1/2"-20 9.14 5.94 27.40 5/8" Imperial
-04 DAUNF1305-0406IN 7/16"-20 9/16"-18 9.93 7.54 28.40 11/16" Imperial
-04 DAUNF1305-0408IN 7/16"-20 3/4"-16 11.13 9.80 27.94 7/8" Imperial
-04 DAUNF1305-0410IN 7/16"-20 7/8"-14 12.70 12.29 23.90 1" Imperial
-04 DAUNF1305-0412IN 7/16"-20 1-1/16"-12 15.09 15.47 27.70 1-1/4" Imperial
-04 DAUNF1305-0416IN 7/16"-20 1-5/16"-12 15.09 9.25 25.40 1-1/2" Imperial
-05 DAUNF1305-0504 1/2"-20 7/16"-20 9.14 4.37 29.46 19 mm Metric
-05 DAUNF1305-0508 1/2"-20 3/4"-16 11.13 9.93 30.73 22 mm Metric
-05 DAUNF1305-0504IN 1/2"-20 7/16"-20 9.14 4.37 29.46 3/4" Imperial
-05 DAUNF1305-0508IN 1/2"-20 3/4"-16 11.13 9.93 30.73 7/8" Imperial
-06 DAUNF1305-0604 9/16"-18 7/16"-20 9.14 4.37 29.50 22 mm Metric
-06 DAUNF1305-0605 9/16"-18 1/2"-20 9.14 5.94 31.50 22 mm Metric
-06 DAUNF1305-0606 9/16"-18 9/16"-18 9.93 7.54 31.00 22 mm Metric
-06 DAUNF1305-0608 9/16"-18 3/4"-16 11.13 9.93 29.50 22 mm Metric
-06 DAUNF1305-0610 9/16"-18 7/8"-14 12.70 12.29 30.23 27 mm Metric
-06 DAUNF1305-0612 9/16"-18 1-1/16"-12 15.09 15.47 27.70 32 mm Metric
-06 DAUNF1305-0616 9/16"-18 1-5/16"-12 15.09 12.90 25.40 41 mm Metric
-06 DAUNF1305-0620 9/16"-18 1-5/8"-12 15.09 12.92 25.40 50 mm Metric
-06 DAUNF1305-0604IN 9/16"-18 7/16"-20 9.14 4.37 29.50 13/16" Imperial
-06 DAUNF1305-0605IN 9/16"-18 1/2"-20 9.14 5.94 31.50 13/16" Imperial
-06 DAUNF1305-0606IN 9/16"-18 9/16"-18 9.93 7.54 31.00 13/16" Imperial
-06 DAUNF1305-0608IN 9/16"-18 3/4"-16 11.13 9.93 29.50 7/8" Imperial
-06 DAUNF1305-0610IN 9/16"-18 7/8"-14 12.70 12.29 30.23 1" Imperial
-06 DAUNF1305-0612IN 9/16"-18 1-1/16"-12 15.09 15.47 27.70 1-1/4" Imperial
-06 DAUNF1305-0616IN 9/16"-18 1-5/16"-12 15.09 12.90 25.40 1-1/2" Imperial
-06 DAUNF1305-0620IN 9/16"-18 1-5/8"-12 15.09 12.92 25.40 1-7/8" Imperial
-08 DAUNF1305-0804 3/4"-16 7/16"-20 9.14 4.37 35.40 27 mm Metric
-08 DAUNF1305-0806 3/4"-16 9/16"-18 9.93 7.54 36.83 27 mm Metric
-08 DAUNF1305-0808 3/4"-16 3/4"-16 11.13 9.93 35.81 27 mm Metric
-08 DAUNF1305-0810 3/4"-16 7/8"-14 12.70 12.29 33.30 27 mm Metric
-08 DAUNF1305-0812 3/4"-16 1-1/16"-12 15.09 15.47 37.59 32 mm Metric
-08 DAUNF1305-0814 3/4"-16 1-3/16"-12 15.09 18.26 27.70 36 mm Metric
-08 DAUNF1305-0816 3/4"-16 1-5/16"-12 15.09 17.50 25.40 41 mm Metric
-08 DAUNF1305-0820 3/4"-16 1-5/8"-12 15.09 17.50 25.40 50 mm Metric
-08 DAUNF1305-0824 3/4"-16 1-7/8"-12 15.09 33.32 32.30 55 mm Metric
-08 DAUNF1305-0804IN 3/4"-16 7/16"-20 9.14 4.37 35.40 1" Imperial
-08 DAUNF1305-0806IN 3/4"-16 9/16"-18 9.93 7.54 36.83 1" Imperial
-08 DAUNF1305-0808IN 3/4"-16 3/4"-16 11.13 9.93 35.81 1" Imperial
-08 DAUNF1305-0810IN 3/4"-16 7/8"-14 12.70 12.29 33.30 1" Imperial
-08 DAUNF1305-0812IN 3/4"-16 1-1/16"-12 15.09 15.47 37.59 1-1/4" Imperial
-08 DAUNF1305-0814IN 3/4"-16 1-3/16"-12 15.09 18.26 27.70 1-3/8" Imperial
-08 DAUNF1305-0816IN 3/4"-16 1-5/16"-12 15.09 17.50 25.40 1-1/2" Imperial
-08 DAUNF1305-0820IN 3/4"-16 1-5/8"-12 15.09 17.50 25.40 1-7/8" Imperial
-08 DAUNF1305-0824IN 3/4"-16 1-7/8"-12 15.09 33.32 32.30 2-1/8" Imperial
-10 DAUNF1305-1008 7/8"-14 3/4"-16 11.13 9.93 38.10 30 mm Metric
-10 DAUNF1305-1010 7/8"-14 7/8"-14 12.70 12.50 38.00 30 mm Metric
-10 DAUNF1305-1012 7/8"-14 1-1/16"-12 15.09 15.47 39.60 32 mm Metric
-10 DAUNF1305-1016 7/8"-14 1-5/16"-12 15.09 21.44 28.50 41 mm Metric
-10 DAUNF1305-1020 7/8"-14 1-5/8"-12 15.09 20.47 25.40 50 mm Metric
-10 DAUNF1305-1024 7/8"-14 1-7/8"-12 15.09 33.32 32.30 55 mm Metric
-10 DAUNF1305-1008IN 7/8"-14 3/4"-16 11.13 9.93 38.10 1-1/8" Imperial
-10 DAUNF1305-1010IN 7/8"-14 7/8"-14 12.70 12.50 38.00 1-1/16" Imperial
-10 DAUNF1305-1012IN 7/8"-14 1-1/16"-12 15.09 15.47 39.60 1-1/4" Imperial
-10 DAUNF1305-1016IN 7/8"-14 1-5/16"-12 15.09 21.44 28.50 1-1/2" Imperial
-10 DAUNF1305-1020IN 7/8"-14 1-5/8"-12 15.09 20.47 25.40 1-7/8" Imperial
-10 DAUNF1305-1024IN 7/8"-14 1-7/8"-12 15.09 33.32 32.30 2-1/8" Imperial
-12 DAUNF1305-1206 1-1/16"-12 9/16"-18 9.93 7.54 39.70 36 mm Metric
-12 DAUNF1305-1208 1-1/16"-12 3/4"-16 11.13 9.93 41.90 36 mm Metric
-12 DAUNF1305-1210 1-1/16"-12 7/8"-14 12.70 12.29 45.50 36 mm Metric
-12 DAUNF1305-1212 1-1/16"-12 1-1/16"-12 15.09 15.47 46.50 36 mm Metric
-12 DAUNF1305-1216 1-1/16"-12 1-5/16"-12 15.09 21.44 43.69 41 mm Metric
-12 DAUNF1305-1220 1-1/16"-12 1-5/8"-12 15.09 24.92 25.40 50 mm Metric
-12 DAUNF1305-1224 1-1/16"-12 1-7/8"-12 15.09 33.32 32.30 55 mm Metric
-12 DAUNF1305-1232 1-1/16"-12 2-1/2"-12 15.09 44.50 36.30 45 mm Metric
-12 DAUNF1305-1206IN 1-1/16"-12 9/16"-18 9.93 7.54 39.70 1-3/8" Imperial
-12 DAUNF1305-1208IN 1-1/16"-12 3/4"-16 11.13 9.93 41.90 1-3/8" Imperial
-12 DAUNF1305-1210IN 1-1/16"-12 7/8"-14 12.70 12.29 45.50 1-3/8" Imperial
-12 DAUNF1305-1212IN 1-1/16"-12 1-1/16"-12 15.09 15.47 46.50 1-3/8" Imperial
-12 DAUNF1305-1216IN 1-1/16"-12 1-5/16"-12 15.09 21.44 43.69 1-1/2" Imperial
-12 DAUNF1305-1220IN 1-1/16"-12 1-5/8"-12 15.09 24.92 25.40 1-7/8" Imperial
-12 DAUNF1305-1224IN 1-1/16"-12 1-7/8"-12 15.09 33.32 32.30 2-1/8" Imperial
-12 DAUNF1305-1232IN 1-1/16"-12 2-1/2"-12 15.09 44.50 36.30 1-3/4" Imperial
-14 DAUNF1305-1412 1-3/16"-12 1-1/16"-12 15.09 15.47 43.50 41 mm Metric
-14 DAUNF1305-1416 1-3/16"-12 1-5/16"-12 15.09 21.44 43.70 41 mm Metric
-14 DAUNF1305-1412IN 1-3/16"-12 1-1/16"-12 15.09 15.47 43.50 1-1/2" Imperial
-14 DAUNF1305-1416IN 1-3/16"-12 1-5/16"-12 15.09 21.44 43.70 1-1/2" Imperial
-16 DAUNF1305-1612 1-5/16"-12 1-1/16"-12 15.09 15.47 46.00 41 mm Metric
-16 DAUNF1305-1616 1-5/16"-12 1-5/16"-12 15.09 21.44 45.97 41 mm Metric
-16 DAUNF1305-1620 1-5/16"-12 1-5/8"-12 15.09 31.25 25.40 50 mm Metric
-16 DAUNF1305-1624 1-5/16"-12 1-7/8"-12 15.09 31.27 25.40 55 mm Metric
-16 DAUNF1305-1632 1-5/16"-12 2-1/2"-12 15.09 31.26 25.40 70 mm Metric
-16 DAUNF1305-1612IN 1-5/16"-12 1-1/16"-12 15.09 15.47 46.00 1-5/8" Imperial
-16 DAUNF1305-1616IN 1-5/16"-12 1-5/16"-12 15.09 21.44 45.97 1-5/8" Imperial
-16 DAUNF1305-1620IN 1-5/16"-12 1-5/8"-12 15.09 31.25 25.40 1-7/8" Imperial
-16 DAUNF1305-1624IN 1-5/16"-12 1-7/8"-12 15.09 31.27 25.40 2-1/8" Imperial
-16 DAUNF1305-1632IN 1-5/16"-12 2-1/2"-12 15.09 31.26 25.40 2-3/4" Imperial
-20 DAUNF1305-2012 1-5/8"-12 1-1/16"-12 15.09 15.47 50.80 50 mm Metric
-20 DAUNF1305-2016 1-5/8"-12 1-5/16"-12 15.09 21.44 50.00 50 mm Metric
-20 DAUNF1305-2020 1-5/8"-12 1-5/8"-12 15.09 27.38 50.00 50 mm Metric
-20 DAUNF1305-2024 1-5/8"-12 1-7/8"-12 15.09 33.32 44.45 55 mm Metric
-20 DAUNF1305-2032 1-5/8"-12 2-1/2"-12 15.09 39.22 25.40 70 mm Metric
-20 DAUNF1305-2012IN 1-5/8"-12 1-1/16"-12 15.09 15.47 50.80 2" Imperial
-20 DAUNF1305-2016IN 1-5/8"-12 1-5/16"-12 15.09 21.44 50.00 2" Imperial
-20 DAUNF1305-2020IN 1-5/8"-12 1-5/8"-12 15.09 27.38 50.00 2" Imperial
-20 DAUNF1305-2024IN 1-5/8"-12 1-7/8"-12 15.09 33.32 44.45 2-1/8" Imperial
-20 DAUNF1305-2032IN 1-5/8"-12 2-1/2"-12 15.09 39.22 25.40 2-3/4" Imperial
-24 DAUNF1305-2416 1-7/8"-12 1-5/16"-12 15.09 21.44 48.50 60 mm Metric
-24 DAUNF1305-2420 1-7/8"-12 1-5/8"-12 15.09 27.38 47.80 60 mm Metric
-24 DAUNF1305-2424 1-7/8"-12 1-7/8"-12 15.09 33.32 50.80 60 mm Metric
-24 DAUNF1305-2432 1-7/8"-12 2-1/2"-12 15.09 44.50 36.60 70 mm Metric
-24 DAUNF1305-2416IN 1-7/8"-12 1-5/16"-12 15.09 21.44 48.50 2-1/4" Imperial
-24 DAUNF1305-2420IN 1-7/8"-12 1-5/8"-12 15.09 27.38 47.80 2-1/4" Imperial
-24 DAUNF1305-2424IN 1-7/8"-12 1-7/8"-12 15.09 33.32 50.80 2-1/4" Imperial
-24 DAUNF1305-2432IN 1-7/8"-12 2-1/2"-12 15.09 44.50 36.60 2-3/4" Imperial
-32 DAUNF1305-3224 2-1/2"-12 1-7/8"-12 15.09 33.32 56.50 73 mm Metric
-32 DAUNF1305-3224IN 2-1/2"-12 1-7/8"-12 15.09 33.32 56.50 2-7/8" Imperial
