DP1MFF Straight Connector Metric Female - Braided Hose And Spiral Hose

  • DCompanyDME
  • PProduct RangeHose Fitting
  • 1Fitting StructureStraight
  • MThread TypesMetric
  • FConnection TypeFemale
  • FSealing MethodO Rings
  • DME&JDE Code: DP1MFF
  • Product Type: Hose Fitting
  • Hose Fitting Type: Insert
  • Thread Type: UNF
  • Structure: Straight
  • Connection Type: Female
  • Sealing Method: O rings
Technical Data of DP1MFF
  • -14
  • -16
  • -18
  • -20
  • -22
  • -24
  • -30
  • -36
  • -42
  • -52
A drawing of DP1MFF straight hose fitting insert connector.

Note:

  1. Part number of this chart is for use with braided hoses.
  2. If use with spiral hoses, hose fitting series number is DP1MFF-XXXXR
- Part Number F (Thread) Ø H L S
- - Metric mm mm mm mm
-01 DP1MFF-1404 M14×1.5 1/4" 15.5 44.0 19
-16 DP1MFF-1604 M16×1.5 1/4" 15.0 43.5 19
-18 DP1MFF-1804 M18×1.5 1/4" 16.0 44.5 22
-20 DP1MFF-2006 M20×1.5 3/8" 17.0 47.0 27
-22 DP1MFF-2208 M22×1.5 1/2" 17.5 48.8 27
-24 DP1MFF-2408 M24×1.5 1/2" 17.5 48.8 30
-30 DP1MFF-3010 M30×2 5/8" 19.2 58.8 36
-30 DP1MFF-3012 M30×2 3/4" 19.2 58.8 36
-36 DP1MFF-3612 M36×2 3/4" 20.7 60.3 46
-36 DP1MFF-3616 M36×2 1" 20.7 69.0 46
-42 DP1MFF-4216 M42×2 1" 26.0 73.2 50
-42 DP1MFF-4220 M42×2 1-1/4" 26.0 80.0 50
-52 DP1MFF-5220 M52×2 1-1/4" 26.0 80.0 60
-52 DP1MFF-5224 M52×2 1-1/2" 26.0 94.0 60
