The series of SCM25-A hose crimping machines (Handhebel Type) are the portable types, which are suitable for field operation or frequent moving maintenance. SCM25-Ais a highly cost-effective machine developed and designed in collaboration with a French hydraulic team. The small and portable machine is driven by manual hydraulic pump and can be reset mechanically, which greatly reduces the labor intensity. The special material has high strength performance and the glossiness of work surface reaches a highest level after CNC and heat treatment. All of above enable it to be the best choice for your maintenance and field operation!
Machine head
Machine body
Battery case
Unloading valve
Hand pump
Dies cabinet
Size regulator
Indicator light
Indicator check valve
| Max Hydraulic Hose | 25mm ( 2SN ) |
| Crimping Range | 47mm ( 2SN 1” Ferrule ) |
| Die Type and Quantity | 7 PCS |
| Master Die Length | 55 mm |
| Max Opening | 52 mm |
| Hand Pump Pressure | 700 Bar ( MADE IN CHINA ) |
| Speed of Crimping | Standard Speed |
| Crimping Force | 1000 KN |
| Control | Micro Dail |
| L × W × H | 305 × 400 × 280 mm |
| Weight | 25.5 KGS |
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 14 | 14-16 | 14 | 60 |
| 2 | 16 | 16-19 | 16 | 60 |
| 3 | 19 | 19-22 | 19 | 60 |
| 4 | 23 | 23-27 | 23 | 60 |
| 5 | 27 | 26-31 | 27 | 60 |
| 6 | 31 | 31-35 | 31 | 60 |
| 7 | 35 | 35-39 | 35 | 60 |
Notes: standard die sets are included, others are options.
